MIG

XC(27.5“,29")
32MM
DETAIL

SPECIFICATIONS

MIG 27.5

  • Weight : 3260 grams(STKM)/ 2680 grams(AL)
  • Wheel Size : 27.5 inch
  • Travel : 100mm,120mm,130mm
  • Stanchion : 32mm(STKM, Cr-Plating/ AL)
  • Spring : Coil(Soft, Standard, Firm), Air spring
  • Damper : RC, LO
  • Adjustment : 1. Compression, Rebound, Preload spring
  •                          2. Lock without ReboundSteerer : Taper(STKM)
  • Axle: 9-100mm or Boost 15-110 Dropout
  • Offset : 46mm
  • Max Rotor Size: 180mm

MIG 29

  • Weight : 3300 grams(STKM)/ 2740 grams(AL)
  • Wheel Size : 29 inch
  • Travel : 100mm,120mm,130mm
  • Stanchion : 32mm(STKM, Cr-Plating/ AL)
  • Spring : Coil(Soft, Standard, Firm), Air spring
  • Damper : RC, LO
  • Adjustment : 1. Compression, Rebound, Preload spring
  •                          2. Lock without ReboundSteerer : Taper(STKM)
  • Axle: 9-100mm or Boost 15-110 Dropout
  • Offset : 51mm
  • Max Rotor Size: 180mm
